Cleanroom Wipes
Polyester Cleanroom Wipes 1009C Mesh 155 g/m²
| Material | Polyester yarn |
|---|---|
| Construction | Knitted mesh |
| Basis weight | 155 g/m² |
| Thickness | 0.50 mm |
| Edge options | Laser sealed; Ultrasonic sealed; Hot cut; Wide ultrasonic seal |
| Washing designations | Class 100; Class 1000 |
| Size options | 4 in; 6 in; 9 in; 12 in; Custom sizes |
| Listed water absorption | ≥230 — unit/method to confirm |
| Packaging | Vacuum inner pack with two-layer outer packaging |
Washing designations describe processing options, not sterility. Absorption figures require a confirmed test unit and method before comparison.
1009C is a polyester mesh wipe positioned for controlled cleaning in semiconductor and disk-drive environments. Its heavier fabric face supports repeated folding while the selected washing and edge process determine the finished wipe configuration.
Separate cleaning action from cleanliness limits
The mesh supplies the mechanical contact needed to lift soil; the wipe's extractables and particle release determine whether that cleaning step introduces another problem. For a sensitive process, assess these two requirements separately instead of relying on a general low-lint description.
1009C can be considered for workstations, fixtures and approved equipment surfaces where a substantial folded sheet is useful. Direct contact with a critical component requires its own qualification using the process solvent and the applicable ion or residue limits.
Build a useful qualification request
- Identify the surface and the contaminant being removed.
- State the solvent, contact time and folding method used in production.
- Request the relevant particle, ionic-residue or nonvolatile-residue evidence for the selected finish.
- Record the wash designation and edge option in the purchase specification.
Keep unopened packs protected through transfer and avoid placing an exposed stack on an uncontrolled bench. The packaging protects the supplied condition only until it is opened and handled.
Sheet packing
9 in: 150 sheets/bag; 6 in: 150 sheets/bag; 4 in: 600 sheets/bag. Carton quantity to be confirmed.
Fabric and product details
Documentation to request
RoHS; Halogens; Silicone oil; Ionic contamination; Liquid particle count (LPC); Composition; Cleanliness.
Confirm report availability, test method and applicability to the selected finished product before ordering.
Application areas
Laboratory research; Semiconductor processes; LCD panels; Optical products; Precision electronics; Pharmaceutical production; Biomedical work areas.
Choose the contact surface, cleaner and acceptance criteria for the actual task. An application listing does not establish sterile or medical-device status.
Contact shengtongjh to discuss the sheet size, finishing and packing required for your application.
