Cleanroom Wipes
Microfiber Cleanroom Wipes 8009D 210 g/m²
| Material | Polyester and nylon |
|---|---|
| Construction | Knitted straight texture |
| Basis weight | 210 g/m² |
| Thickness | 0.36 mm |
| Edge options | Laser sealed; Ultrasonic sealed; Hot cut; Wide ultrasonic seal |
| Washing designations | Class 10; Class 100; Class 1000 |
| Size options | 4 in; 6 in; 9 in; 12 in; Custom sizes |
| Listed water absorption | ≥300 — unit/method to confirm |
| Packaging | Vacuum inner pack with two-layer outer packaging |
Washing designations describe processing options, not sterility. Absorption figures require a confirmed test unit and method before comparison.
8009D is a heavier polyester-nylon microfiber wipe with a straight knitted texture for precision optical cleaning. It is a candidate for suitable camera, laser-system and glass surfaces where film removal must be controlled.
Optical cleaning begins with the surface specification
A camera lens, protective window and laser optic may have different coatings and cleaning limits. Before using 8009D, identify the surface and the cleaning liquid approved for it. Use the cloth only where the component's procedure permits wiping contact.
The fine microfiber face supplies close contact for collecting loosened film. It cannot prevent damage from a trapped hard particle, so remove loose debris before the wet-cleaning pass.
Small contact areas
Choose a compact fold with the sealed edge tucked away. Avoid applying force through a fingernail or an uneven support that concentrates pressure.
Final acceptance
Inspect after evaporation using the optical process's criteria. A visually clear surface may still need residue or particle measurement where performance is sensitive.
Keep separate wipes for optical surfaces and surrounding housings. Cleaning a housing first can load the cloth with particles that should never reach the optic.
Sheet sizes and packing
| Sheet size | Sheets / bag | Bags / carton |
|---|---|---|
| 4 × 4 in | 400 | 20 |
| 6 × 6 in | 100 | 20 |
| 9 × 9 in | 100 | 10 |
Confirm the selected size, edge, washing condition and packing together when ordering.
Fabric and product details
Documentation to request
RoHS; Silicone oil; Composition; Cleanliness.
Confirm report availability, test method and applicability to the selected finished product before ordering.
Application areas
Laboratory research; Semiconductor processes; LCD panels; Optical products; Precision electronics; Pharmaceutical production; Biomedical work areas.
Choose the contact surface, cleaner and acceptance criteria for the actual task. An application listing does not establish sterile or medical-device status.
Contact shengtongjh to discuss the sheet size, finishing and packing required for your application.
